| select | Inquiry | Designation | Principal Dimensions(mm) | Basic Load Ratings(KN) | Limited Speed(rpm) | Weight | ||||
|---|---|---|---|---|---|---|---|---|---|---|
| d | D | B | rs?min | Dynamic(Cr) | Static(Cor) | Oil | (kg) | |||
| 29230 | 150 | 215 | 39 | 1.5 | 340 | 1340 | 1800 | 4.56 | ||
| 29232 | 160 | 225 | 39 | 1.5 | 360 | 1460 | 1700 | 4.88 | ||
| 29234 | 170 | 240 | 42 | 1.5 | 425 | 1770 | 1600 | 6.02 | ||
| 29236 | 180 | 250 | 42 | 1.5 | 450 | 1920 | 1600 | 6.27 | ||
| 29238 | 190 | 270 | 48 | 2 | 530 | 2230 | 1400 | 8.8 | ||
| 29240 | 200 | 280 | 48 | 2 | 535 | 2300 | 1400 | 9.14 | ||
